P. 267

   .68 17.3
(+) SPADE TO LATCH
DIN FORM 43650
1/8-27 NPT INLET
.23 MFT
(+) SPADE UNLATCH
.30 7.5
.68
17.3 (+) LEFT LEAD YELLOW TO LATCH
LEAD WIRES
(+) RIGHT LEAD BLUE
TO UNLATCH
                                                                                                                                                      1/8-27 NPT OUT
.59 15
1.13 28.6
2X 8-32 UNC-2B
.88 22.2
                                                                         .30 7.5
.20 5 .40 10.1
                  SERIES 15
SESERRIIES155
  SERIES 15
MODEL 152
MODEL 152 2WNNCC
MAGNETIC LATCHING DIN STYLE COIL
DIN STYLE MAGNETIC LATCHING
MODEL 152
MODEL 152
2WNC
MAGNETIC LATC2HWINNGCCOIL WITH LEADS
MOLDED WITH LEADS MAGNETIC LATCHING
    VALVE SPECIFICATIONS
MAX. OPER.
PRESS. DIFF. ORIFICE SIZE
DC N.C.
500 1/32 250 3/64 160 1/16
75 3/32 50 1/8
ORDERING INFORMATION:
CV FACTOR N.C.
.022 .055 .075 .130 .230
VALVE NUMBER
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (152J2DGLM 12/DC) REPAIR PACK (K152JDLM DC)
WHEN ORDERING OPERATORS ADD THE LETTER ā€œOā€ TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER ā€œDā€: EXAMPLE: OPERATOR (O152J2DGLM 12/DC)
LEAD WIRE
152G2DGLM 152H2DGLM 152J2DGLM 152K2DGLM 152N2DGLM
DIN STYLE
152G2DELM 152H2DELM 152J2DELM 152K2DELM 152N2DELM
       www.peterpaul.com >>> 1-860-229-4884 >>> 265
