 1.05 26.7
1/8-27 NPT OUTLET
.59 15
1.38 35.1
2X 8-32 UNC-2B
.71 18
2.38 60.5
1/2-14 NPT CONDUIT
1.50 38
.30 .20 7.5 5
.40 10.1
VALVE SPECIFICATIONS
MAX. OPER.
PRESS. DIFF. ORIFICE SIZE
AC DC N.C.
CV FACTOR N.C.
.022 .055 .075 .134 .156 .230 .292
GROMMET HOUSING 1/8 NPT PORTS
52G8DGM 52H8DGM 52J8DGM 52V8DGM 52K8DGM 52N8DGM 52O8DGM
CONDUIT HOUSING 1/8 NPT PORTS
52G8DCM 52H8DCM 52J8DCM 52V8DCM 52K8DCM 52N8DCM 52O8DCM
500 (1000)* 400 (700)* 200 (470) 150 (270) 100 (260) 75 (135)
40 50)
250 (1000)* 150 (450) 100 (325) 75 (210) 45(175) 25 (100) 10 (20)
1/32 3/64 1/16 5/64 3/32 1/8 5/32
SERIES 50
SERIES 50
SERIES 50
SERIES 50
MODEL 52
MODEL 52
MODEL 52
MODEL 52
2WNC
2WNC
2WNC
2WNC
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
VALVE NUMBER
CONDUIT CONNECTION
GROMMET HOUSING WITH LEADS
* FKM seals not recommended for pressure ratings above 500 PSI.
ORDERING INFORMATION:
1/8-27 NPT INLET
2X .30
7.5 1.00
.23 MFT 25.3
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (52J8DGM 120/60) REPAIR PACK (K52JDD AC)
WHEN ORDERING OPERATORS ADD THE LETTER ā€œOā€ TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER ā€œDā€: EXAMPLE: OPERATOR (O52J8DGM 120/60)
